CN-50P.1 Pneumatic Coil Nailer
The CN-50P.1 Pneumatic Coil Nailer is a compact, high‑speed pneumatic coil nailer engineered for pallet repair, crating, industrial packaging, fencing, and light‑to‑medium wood assembly. Designed for fast, repetitive fastening, it delivers reliable driving power for shorter‑length coil nails while maintaining excellent balance, low recoil, and smooth operation. Its durable construction and efficient feeding system make it ideal for continuous use in industrial and workshop environments.
Product Information
FEATURES
- Accepts Both Wire & Plastic Sheet Collated Nails
- Powerful Motor with Minimum Recoil
- Tool-Free Depth Adjustment
- Light-Weight Only 1.6 kg (3.5 lbs)
- Clear Magazine Cover to See Nail Quantity
- Removable No-Mar Rubber Pad with Holder in Magazine
- Tool-Free Selectable Trigger – Change from Single
- Sequential Trigger Available
FASTENERS
- 15° Wire Or Plastic Sheet Collated Nails
- Wire Collated Length: 27 to 50 mm (1 1/8 to 2 inch)
- Plastic Collated Length: 25 to 50 mm (1 to 2 inch)
- Wire Collated Shank Diameter: 1.8 to 2.1 mm (0.072 to 0.083 inch)
- Plastic Collated Shank Diameter: 1.6 to 2.1 mm (0.063 to 0.083 inch)
- Shank Type: Smooth, Ring & Screw
APPLICATIONS
SPECIFICATIONS
- Weight: 1.6 kgs (3.5 lbs)
- Dimensions (L*W*H): 251 x 117 x 282 mm (9 7/8 x 4 5/8 x 11 1/8 inch)
- Operated Pressure: 5 - 7 kg/cm2 (70 - 100 psi)
- Load Capacity: Wire Nails 250 - 400 Nails / Plastic Nails 200
