AMC-38 Metal Connector Nailer
The AMC-38 Metal Connector Nailer is a high‑performance metal connector nailer engineered for fastening structural hardware such as joist hangers, hurricane ties, straps, anchors, and other steel connectors used in framing and construction. Designed to drive specialized hardened nails through pre‑punched metal plates, the AMC‑38 delivers the high driving force, precision, and reliability required for code‑compliant structural fastening.
Product Information
FEATURES
- Light Weight, Impact Design to Reach The Tightest Corners.
- Nail Point Sticks Out for Accurate Metal Connector Hole Aiming and Fastening.
- Sequential Trigger for Precise Nail Placement.
- Swivel Belt Hook for Both Left And Right-Handed Users.
- Over-Molded Rubber Grip for Added Comfort and Less Fatigue.
- Floating Pusher for Quick Re-Loading of Nails.
- Dry-Fire Lock to Prevent Un-Intended Nailing.
- 360° Adjustable Exhaust Deflector.
- Swivel Air-Inlet for Less Hose Tangling.
FASTENERS
- Type: 34° Paper Tape Round Head Nails
- Wire: 3.3 - 4.1 mm (0.131 - 0.162 inch)
- Length: 38 mm (1 1/2 inch)
APPLICATIONS
SPECIFICATIONS
- Weight: 2.25 kgs (4.95 lbs)
- Dimensions (L*W*H): 365 x 90 x 295 mm (14.17 x 3.54 x 11.81 inch)
- Operated Pressure: 5.5 - 7 kg/cm2 (80 - 100 psi)
- Load Capacity: 29 Nails
