LU-851F2 16 GA Medium Crown Stapler
The LU-851F2 16 GA Medium Crown Stapler is a 16‑gauge medium‑crown stapler engineered for framing components, furniture manufacturing, crate and pallet assembly, sub‑flooring, sheathing, and general construction fastening. Medium‑crown staples offer a wider holding footprint than narrow‑crown or fine‑wire staples, making this tool ideal for applications requiring strong structural grip, high pull‑out resistance, and fast production‑rate stapling.
Product Information
FEATURES
- Patented Quick Release Nose Cover
- 360° Adjustable Metal Exhaust
- Heavy Duty, Well Balanced
- Depth Adjustment
- Dedicated Bump Fire Trigger
- Sequential Trigger Available
- Top Load Long Magazine
FASTENERS
- Staple Type: 100/N Series
- Compatible with Hitachi 11200, Omer M2, Senco N Series
- Crown: 11 mm (0.433 inch)
- Wire: 1.60 x 1.40 mm (0.063 x 0.055 inch)
- Length: 25 to 50 mm (1 to 2 inch)
APPLICATIONS
SPECIFICATIONS
- Weight: 2.90 kg (6.50 lbs)
- Dimensions (L*W*H): 343 x 97 x 307 mm (13.5 x 3.8 x 12.1 inch)
- Operated Pressure: 6 - 8 kg/cm2 (85 - 110 psi)
- Load Capacity: 140 Staples
