CJ-32 Jumbo Carton Closing Stapler
The CJ-32 Jumbo Carton Closing Stapler is a heavy‑duty jumbo carton‑closing stapler designed for sealing large, thick, or reinforced corrugated boxes where standard carton staplers may not provide sufficient penetration or holding strength. Built for demanding packaging environments, the CJ‑32 drives jumbo‑size staples that create a deep, secure mechanical lock across heavy‑wall carton flaps, making it ideal for export packaging, industrial goods, and oversized shipments.
Product Information
FEATURES
- Comfortable Rubber Grip
- Rear Exhaust
- Trigger Actuated
- Depth of Clinch and Penetration Adjustable
- Designed for Tri-Wall Corrugated Cardboards (15 - 24 mm Total Thickness)
FASTENERS
- Staple Type: SW9060 Series
- Crown: 32.00 mm (1.260 inch)
- Wire: 2.30 x 1.40 mm (0.091 x 0.060 inch)
- Length: 28 to 35 mm (1 1/8 to 1 3/8 inch)
APPLICATIONS
SPECIFICATIONS
- Weight: 6.0 kg (13.2 lbs)
- Dimensions (L*W*H): 360 x 174 x 335 mm (14.17 x 6.85 x 13.19 inch)
- Operated Pressure: 5 - 7 kg/cm2 (70 - 100 psi)
- Load Capacity: 100 Staples
