AW095A 1/2″ Air Composite Impact Gun
The AW095A 1/2″ Air Composite Impact Gun is a lightweight, high‑performance 1/2″ composite air impact gun engineered for automotive service, machinery maintenance, industrial assembly, and workshop repair. Built around a durable composite housing and a high‑efficiency impact mechanism, it delivers strong torque with reduced weight, making it ideal for technicians who need power, speed, and all‑day comfort.
Product Information
FEATURES
- 10 PCS/CTN 23.5/24.5 KG CUFT 1.6'
- Mechanism: Twin Hammer
- Composite and magnesium material.
- Highest durable Japanese steel anvil.
- Handle exhaust.
- Forward: 3 positions, Reverse: 1 position
- The cylinder is using material of FCD45 and has special heat treat, it has high wear resistance.
- Blade with spring mounted, make sure the blades can be opened when working.
- Simple structure, easy to service and repair.
SPECIFICATIONS
- Square Drive: 12.7 mm (1/2 inch)
- Bolt Capacity: M24
- Overall Length: 17.9 cm (6 7/8 inch)
- Avg. Air Consumption: 5.5 CFM (158 L/min)
- Air Inlet: 6.35 mm (1/4 inch)
- Hose Size(I.D.): 9.525 mm (3/8 inch)
- Air Pressure: 6.3 kg/cm2 (90 PSI)
- Torque(5 sec.): 800 ft-lb (1080 N.m)
- Max. Torque(10 sec.): 950 ft-lb (1283 N.m)
- Net Weight: 1.70 kgs (3.75 lbs)
- Free Speed: 8500 RPM
- Vibration: 8.1 m/s2
